Bosch CCSE-DL CCS700 Conference Delegate Unit

Send Inquiry

Request To Call Back

Bosch CCSE-DL CCS700 Conference Delegate Unit

Name: Bosch CCSE-DL CCS700 Conference Delegate Unit
Brand: EBUILDING TECHNOLOGIES
Price: 9800 INR
Availability: InStock

Price 9800 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Bosch CCSE-DL CCS700 Conference Delegate Unit Specification

Speaker
Built-in loudspeaker

Sensitivity
-44 dB (microphone)

Channels
1 channel (standard)

Noise Control
Unidirectional microphone with noise rejection

Use
Conference system delegate control

Product Type
Conference Delegate Unit

Material
High-quality ABS plastic

Power Supply
24 V DC via CCU (from power supply unit) or via system cable

Output Power
>1W (internal loudspeaker)

Input Power
Via system connection

Dimension (L*W*H)
54 x 175 x 155 mm

Color
Dark grey

Weight
approx. 0.9 kg

Installation
Tabletop

Maximum Power Consumption
< 1.3 W

Microphone Type
Flexible gooseneck microphone with red LED indicator

Cable Length
2 m (fixed connection cable)

Controls
Microphone ON/OFF button, LED indicator

Operating Temperature Range
0°C to +35°C

Headphone Output
3.5 mm stereo jack with volume control

Microphone Frequency Response
200 Hz to 12.5 kHz

About Bosch CCSE-DL CCS700 Conference Delegate Unit

The CCS700 Ultro discussion system is suitable foruse in meetings and conference venues with a limitednumber of participants.The CCSE-DL delegate units enable participants toactively take part in the meeting proceedings. A builtin microphone allows them to speak to the otherdelegates, and they can listen to the discussion usingthe built-in loudspeaker or (optional) personalheadphones.

Microphone with flexible stem and light ring

The microphone has a flexible stem, which is easilyadjustable to suit personal preferences. It also allowstwo people to use the same delegate unit as they canpull the microphone towards them, when it is requiredto speak.The microphone is fixed to the base of thedelegate unit.Incorporated into the head of themicrophone is a light ring which illuminates red when the microphone is on.

Built in loudspeaker

Loudspeaker volume is set centrally at the control unitfor all delegate units. To prevent acoustic feedback,the built-in loudspeaker is automatically muted whenthe microphone is on.

Compact, attractive design

Built-in volume control for headphones

Microphone with flexible stem and light ring

Two headphone sockets

Flexible and User-Friendly Conference Communication

The Bosch CCSE-DL CCS700 Delegate Unit stands out with its flexible gooseneck microphone and intuitive controls. The red LED indicator clearly shows when the unit is active, while the headphone and volume controls allow delegates to manage their audio experience effectively. Its unidirectional microphone ensures excellent noise rejection, making conversations clear in busy meeting rooms or conference halls.

Installation Designed for Simplicity and Reliability

Installing the delegate unit is straightforward, as it is engineered for tabletop placement and comes with a 2-meter fixed connection cable. Power is supplied easily via the central control unit or system cable, minimizing setup time and cabling complexity. The durable ABS plastic housing and stable design ensure it remains securely in place, even in actively used conference settings.

FAQ's of Bosch CCSE-DL CCS700 Conference Delegate Unit:

Q: How do I operate the Bosch CCSE-DL CCS700 conference delegate unit during a meeting?

A: To operate the delegate unit, simply press the Microphone ON/OFF button to activate or deactivate your microphone. The red LED indicator will illuminate when the microphone is active. You can regulate the audio level using the volume control on the 3.5 mm headphone output.

Q: What are the main benefits of the unidirectional microphone design?

A: The unidirectional microphone is engineered to focus on the speaker's voice while minimizing background noise, resulting in improved speech clarity. This feature is especially valuable in environments with multiple conversations or background activities.

Q: When should the Bosch CCSE-DL CCS700 unit be used in a conference setting?

A: This unit is ideal for structured meetings, seminars, and formal assemblies where delegates need to speak and listen clearly. It provides reliable audio management in boardrooms, government councils, corporate conferences, and educational forums.

Q: Where should the CCSE-DL unit be positioned for optimal performance?

A: Place the unit on a flat tabletop surface within comfortable reach of the delegate. The flexible gooseneck microphone can be adjusted for optimal voice capture. Ensure the fixed connection cable can reach the central control unit or system cable port.

Q: What is the installation process for this conference delegate unit?

A: Installation involves setting the unit on the meeting table and connecting the 2-meter fixed cable to the central control unit or system cable. The device draws power from the system, and no additional power source is needed. Follow the manufacturer's guidelines for proper system integration.

Q: How does the built-in loudspeaker benefit participants?

A: The internal loudspeaker, with output power greater than 1 W, enables delegates to clearly hear other speakers, ensuring everyone remains engaged and informed throughout the meeting.

Q: Is the Bosch CCSE-DL CCS700 suitable for use in varying climates across India?

A: Yes, the unit operates efficiently within a temperature range of 0C to +35C, making it suitable for use in a variety of indoor environments commonly encountered across India.
