Bosch 90w All In One Amplifier

Price 18805.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Bosch 90w All In One Amplifier Specification

Alarm
No dedicated alarm function

Noise Control
<3 mV residual noise

Impedance
4, 8, 100V outputs

Speaker
Compatible with 4, 8, & 100V speakers

Channels
4 Mic & 1 Aux/Line input

Sensitivity
1V (Line), 200mV (Mic)

Use
Public address, announcements, background music

Product Type
All In One Amplifier

Material
Metal (Chassis), Plastic (Front Panel)

Power Supply
AC 220V - 240V, 50/60Hz

Output Power
90W

Input Power
Multiple Microphone and Line Inputs

Rated Power
90 Watt

RMS Power
90W

Dimension (L*W*H)
430 mm x 100 mm x 300 mm (approx.)

Color
Black

Weight
8 kg (approx.)

About Bosch 90w All In One Amplifier

The PLENA all-in-one mixer amplifier is a versatilesolution for public address, emergencyannouncements and back-ground-music (BGM)requirements. This high-performance device is easy toinstall and operate.Typical applications of PLENA all-in-one 90W mixeramplifier include use in supermarkets, restaurants,schools, retail chains, canteens, places of worship,gymnasiums etc where BGM provides the rightatmosphere, at the same time announcements can bemade clearly and with ease.

4 microphone inputs with independent level control

USB drive and SD card for MP3 playback

Built-in FM tuner with preset memories

100V/Telephone input with priority and VOX

24 VDC backup power supply input

Versatile Connectivity and Inputs

Equip your audio systems seamlessly with four microphone and one auxiliary/line input. The Bosch 90W amplifier's multiple input options enable effortless setup for announcements, presentations, and background music across varied venues, supporting both professional and commercial requirements.

Built-In Protection and Durability

Stay confident with comprehensive protection circuits, including overload, short circuit, overheat, and DC fault safeguards. Crafted with a robust metal chassis and a sleek plastic front panel, this amplifier is built to withstand frequent use in demanding settings.

Flexible Mounting and Compact Design

Adapt the Bosch 90W amplifier to your environment easily, with the option for tabletop placement or rack mounting (compatible with standard 19-inch racks). Its compact dimensions and reliable cooling system make it suitable for installations where space and temperature management are priorities.

FAQ's of Bosch 90w All In One Amplifier:

Q: How do I connect different speakers to the Bosch 90W All-In-One Amplifier?

A: You can connect a variety of speakers such as 4, 8, and 100V speakers using the screw terminal outputs at the rear panel. Ensure that the speaker impedance matches the respective output terminals to optimize performance and avoid potential damage.

Q: What are the available input options, and how can I use them?

A: The amplifier features four microphone inputs and one auxiliary/line input. You may plug microphones into the dedicated mic inputs for announcements, while music players or external audio sources can be connected through the aux/line input for background music or presentations.

Q: When should I use the tone controls on the amplifier?

A: You can adjust the bass and treble controls on the front panel whenever you wish to tailor the sound to your preference or room acoustics. These controls help enhance clarity and warmth, ensuring your audio output suits different environments and source materials.

Q: Where can the Bosch 90W Amplifier be installed?

A: This amplifier can be placed on any stable tabletop surface or mounted within a standard 19-inch rack (with optional accessories). Its flexible mounting options make it ideal for use in offices, auditoriums, classrooms, and commercial venues.

Q: What is the benefit of the built-in protection features?

A: Integrated safeguards such as overload, short circuit, overheat, and DC protection ensure the amplifier operates reliably and safely, minimizing the risk of operational issues and extending the lifespan of your equipment.

Q: How does the internal cooling system work?

A: The Bosch amplifier uses forced air cooling to maintain optimal internal temperatures during extended use. This system helps prevent overheating and enhances the reliability and efficiency of the amplifier's performance.
